Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage

  • Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage
  • Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage
  • Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage
  • Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage
  • Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage
Place of Origin China
Brand Name FABIA
Certification FM,AMCA,ISO9001,CE,CCS,DNV
Model Number 23 inch ～ 39nch
Document Product Brochure PDF
Minimum Order Quantity 1 set
Price Negotiable
Packaging Details Cartons/Wooden cases
Delivery Time 15-30 work days
Payment Terms L/C, D/A, D/P, T/T, MoneyGram, Western Union
Supply Ability 100-1000 set per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Round Butterfly Damper（Big Diamention） Valve Connection Flange
Material Stainless Steel Valve Body Stainless Steel
ControlMode Manual/Pneumatic/Electric Design Pressure ±6000Pa
Leakage 56l/s/m³（2000Pa） Apply Semiconductors, LCD Panels, Biopharmaceuticals
Highlight

biopharmaceuticals Butterfly Damper

,

Semiconductors Butterfly Damper

,

LCD panels Butterfly Damper
Leave a Message
Product Description

Round Butterfly Damper for Semiconductors, LCD panels and biopharmaceuticals with low leakage



1. Description:



The product is mainly used in industries such as semiconductors, LCD panels, and biopharmaceuticals for ventilation and exhaust system air volume control valves



2. Specification:



Product No. Size Height Thickness
(body)		 Thickness
(blade)		 D(shaft) Control Model
FB-RBD-0600-01 D600 250 2 1.5*2 D30 Manual/Pneumatic/Electric
FB-RBD-0650-02 D650 250 2.5 1.5*2 D30
FB-RBD-0700-03 D700 250 2.5 1.5*2 D30
FB-RBD-0750-04 D750 250 2.5 1.5*2 D30
FB-RBD-0800-05 D800 250 2.5 1.5*2 D30
FB-RBD-0850-06 D850 250 2.5 1.5*2 D30
FB-RBD-0900-07 D900 250 2.5 1.5*2 D30
FB-RBD-0950-08 D950 250 2.5 1.5*2 D30
FB-RBD-1000-09 D1000 250 2.5 1.5*2 D30
FB-RBD-FREE FREE



3. Features:



  • Valve body structure: divided into single blade and multi-blade according to the size
  • Blade:diamond structure
  • Design Pressure:±6000Pa
  • Leakage:56L/s/m³(2000Pa)
  • Sealing element:fluororubber oil seal
  • Beautiful, low noise, and low resistance loss

Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage 0Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage 1Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage 2Round Butterfly Damper For Semiconductors LCD Panels And Biopharmaceuticals With Low Leakage 3
