Gold top valve located in Oubei Town, Wenzhou, China,where can make all kinds of precision balls,including top entry,metal seat and V type balls.On this base,our products range of floating,trunnion,Gate globe check valve ,butterfly valve ,etc.Surely we can design them by customer's special requirements.
 |
| Place of Origin: | 中国 |
| Brand Name: | GOLD TOP |
| Certification: | API602 |
| Model Number: | Z11H |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Packaging Details: | Plywood Case |
| Delivery Time: | 30days |
| Size: | NPS 1/4”～2”(DN8～DN50) | Class: | 50～2500 (PN 20～PN420) |
|---|---|---|---|
| Material: | A105、A350 LF2、A182 F11、A182 F22、A182 F304、A182 F316、A182 F51、B150 C61900、B564 N04400、B546 N06625,etc. | Design Standard: | ISO 15761、API 602、BS 5352、ASME B16.34 |
| Connecting End: | ASME B16.5、ASME B16.25、ASME B16.11 | Operating Temperature: | -29℃～595℃(the Range Of Service Temperature May Vary For Different Materials) |
| Connect: | RF SW BW NPT ENDS | ||
| High Light: | forged steel gate valve,socket weld valve |
||
API602 FORGED STEEL VALVE GLOBE VALVE 150LB 300LB 900LB A105 LF2 F11 integrated flange RF RTJ
Applicable Standards:
●STEEL GLOBE VALVES, API 602
●STEEL VALVES,ASME B16.34
●FACE TO FACE, MANUFACTURER STANDARD
●FACE TO FACE, FLANGED ,ASME B16.10
●END FLANGES,ASME B16.5
●BUTTWELDING ENDS,ASME B16.25
●SOCKET-WELDING ENDS,ASME B16.11
●SCREWED ENDS,ASME B1.20.1
●INSPECTION AND TEST, API 598
Design descriptions:
●OUTSIDE SCREW AND YOKE (OS&Y)
●BOLTED BONNET
●CHOICE OF WB, WELDED BONNET
●LOOSE DISC,CHOICE OF PLUG OR BALL
●SEAT RINGS INTEGRAL WITH BODY
●YOKE INTEGRAL WITH BONNET
●RISING STEM AND HANDWHEEL
●HORIZONTAL SERVICE
●SW,SOCKET-WELDING ENDS
●SC,SCREWED ENDS
●BW,BUTTWELDING ENDS
| Size | NPS 1/2″~2″ |
|---|---|
| Pressure Rating | Class 150~1500 |
| Material | A105,LF2,F5,F9,F11,F22,F304,F304L,F311,F51 |
| Design & Manufacturing Standard | API 602,ASME B16.34,BS 5352 |
| Face to Face | ASME B16.10,EN 558(threaded and sw as per manufacturer’s std) |
| Flanged Dimension | ASME B16.5 |
| Butt Weld Dimension | ASME B16.25 |
| Thread Connection Dimensions | ASME B 1.20.1 |
| Test and Inspection | API 598 |
| Type | Globe |
