Gold top valve located in Oubei Town, Wenzhou, China,where can make all kinds of precision balls,including top entry,metal seat and V type balls.On this base,our products range of floating,trunnion,Gate globe check valve ,butterfly valve ,etc.Surely we can design them by customer's special requirements.
 |
| Place of Origin: | 中国 |
| Brand Name: | GOLD TOP |
| Certification: | API602 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Price to be negotiated in person |
| Packaging Details: | Plywood Case |
| Delivery Time: | 30days |
| Supply Ability: | 100+pcs+30 days |
| Size: | NPS 1/4”～2”(DN8～DN50) | Class: | 150～2500 (PN 20～PN420) |
|---|---|---|---|
| Face To Face: | ASME B16.10 | Material: | Carbon / Stainless / Alloy / Duplex |
| Trim: | Carbon / Stainless / Alloy / Duplex | Ends: | Flanged / SW / NPT |
| High Light: | socket weld valve,hand wheel valve |
||
API602 FORGED STEEL GLOBE VALVE NEEDLE DISC F304 BODY SW ENDS WITH NIPPLE
Type: Globe Valve.
Material: ASTM A105.
Size: 1 1/2 Inch.
Pressure class: Class 2500.
Connection: Welding Flanged Ends.
Operator: Hand Wheel.
Body / Bonnet Structure: BB OS&Y.
Standard: API 602.
Design Standard: ANSI B16.34.
Specification
Valve Material : ASTM A105,A182 F304/F316/F11/F22/F304L/F316L
Valve Rating : Class 2500
Port Size : Standard Port
Size Range : 1/2" - 2"
Connections : Threaded end/Socket end
Working Temperature : (A105) -20°F ~ 800°F ; (S.S.) -20°F ~ 950°F
Service Application : Hydraulic, Chemical, Steam, Oil/ Gas, Power, Petrochemical, Marine,Mining, Construction.
Features
Rising Stem
O.S.&Y. Type
Wedge Disc
Trim: API600 trim no. upon customer's requirement
Manufacturing and Design : API602/ ANSI B16.34
Hydrostatic Test : Shell 9275 PSI; Seat 6800 PSI
Air Test : Seat 80 ~ 100 PSI
A compact but extremely sturdy design for high pressure-temperature service
| Chemical Composition and Mechanical Property For ASTM A105 | |||||||||||||||
| Steel Grade | Chemical Composition | Hardness | Mechanical performance | ||||||||||||
| C(Max) | Mn | P(Max) | S(Max) | Si | Cu(Max) | Ni(Max) | Cr(Max) | Mo(Max) | V(Max) | HB, max | Tensile strength (Min) |
Yield Strength (Min) |
|||
| psi | Mpa | psi | Mpa | ||||||||||||
| A105 | 0.35 | 0.6-1.05 | 0.035 | 0.04 | 0.1-0.35 | 0.4 | 0.4 | 0.3 | 0.12 | 0.12 | 187 | 70000 | 485 | 36000 | 250 |
