Triple Eccentric Offset Wafer Lug Butterfly Valve CF8M 150LB

Triple Eccentric Offset Wafer Lug Butterfly Valve CF8M 150LB

  • Triple Eccentric Offset Wafer Lug Butterfly Valve CF8M 150LB
  • Triple Eccentric Offset Wafer Lug Butterfly Valve CF8M 150LB
Triple Eccentric Offset Wafer Lug Butterfly Valve CF8M 150LB
Product Details:
Place of Origin: CHINA
Brand Name: GTV
Certification: 609
Model Number: D41H
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: WOODEN BOX
Delivery Time: 20DAYS
Payment Terms: T/T, L/C
Supply Ability: 1+PCS+WEEKS
Contact Now
Detailed Product Description
Port Size: Standard, DN50-DN300, DN32-DN2400(NPS1 1/4-NPS96), DN 50-DN 600, DN80 Pressure: Low Pressure, Medium Pressure, 16, PN10/16;125#/150#, PN6/10/16
Temperature Of Media: Medium Temperature, Normal Temperature, Low Temperature, High Temperature, -20-+200 Body Material: Ductile Iron, WCB, CF8, Cast Iron, CI / DI / SS / CS For Butterfly Valve
Connection: Wafer, Flange Ends, Lug, Clamp, U-Section
High Light:

Offset Wafer Lug Butterfly Valve

,

CF8M Lug Butterfly Valve

,

150LB Lug Butterfly Valve

Triple eccentric/Offset metal to metal seat wafer Lug Butterfly Valve 4" CL 600

Valve manufacturer description



Material:

5A

Nominal Pressure

CL600

Nominal Diameter:

4"

End Sealing:

ASME B16.10

Face To Face:

ASME B16.10

Working Temperature:

-294℃~315℃

Test And Inspection:

API 598/ISO 5208

End Connection:

Lug

NACE:

NACE 0175

Certificate:

ISO9001, ISO14001, ISO28001, TS, CE,TUV



Triple Eccentric Offset Wafer Lug Butterfly Valve CF8M 150LB 1

Type: VF910
Material: ASTM A216 Gr. WCB
Pressure class: PN10
Disc: Stainless steel AISI 304
Seat: PTFE
Stem: AISI 304
Gland packing: PTFE
Operation: Lever or manual gearbox
Face to face: ISO 5752
Connection: Mounting between flanges PN10 DIN 2632
Leak rate: ISO 5200 Rate A (No leakage)
Temperature: PTFE: -29°C to +160°C
Options: Pneumatic or electric actuator
  Flanged connections
  Stainless steel versions and other stem materials
  RPTFE seat w/ glass fibers: -29°C to +180°C
  RPTFE seat w/ graphite: -29°C to +210°C
  TFM seat: -100ºC to +260ºC
  Metal seat
  Fire safe version API607



Wafer, PN10
  DIMENSIONS (mm) TOP FLANGE Kv WEIGHT
Item No. DN L H1 H2 Stem ISO 5211 m³/h kg
- 50 43 118 60 11 x 11 F05/07 132 3.9
- 65 46 125 60 11 x 11 F05/07 223 4.5
- 80 47 140 70 14 x 14 F07/10 337 7
- 100 53 157 70 14 x 14 F07/10 527 9
- 125 57 170 70 17 x 17 F07/10 824 12
- 150 56 185 70 17 x 17 F07/10 1186 13.5
- 200 62 220 80 19 x 19 F10/12 1505 22
- 250 68 260 80 22 x 22 F10/12 2294 32
- 300 78 290 100 27 x 27 F12/14 3755 48
- 350 78/92 326 100 27 x 27 F12/14 5129 66
- 400 102 370 120 36 x 36 F14/16 6675 107
- 450 114 395 120 36 x 36 F14/16 8044 130
- 500 127 430 120 46 x 46 F14/16 10169 163
- 600 154 490 150 46 x 46 F16 or F25 17081 278
