Gold top valve  located in Oubei Town, Wenzhou, China,where can make all kinds of precision balls,including top entry,metal seat and V type balls.On this base,our products range of floating,trunnion,Gate globe check valve ,butterfly valve ,etc.Surely we can design them by customer's special requirements.

Home ProductsTrunnion Mounted Ball Valve

Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat

Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat

  • Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat
  • Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat
Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat
Product Details:
Place of Origin: 中国
Brand Name: GOLD TOP
Certification: API6D
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiation
Packaging Details: Plywood Case
Delivery Time: 30 days
Supply Ability: 100+pcs+30 days
Contact Now
Detailed Product Description
Size: 2''-48'' Material: Carbon / Stainless / Duplex Steel
Applicable Standard: API6D Pressure: 150# ~ 2500#
End Connection Standard: ASME B16.5 / ASME B16.47 Type: Trunnion Mounted
High Light:

three way ball valve

,

blowout proof stem ball valve

Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat



Trunnion Mounted Ball Valves

Trunnion Mounted Ball Valves are designed by an experienced team that possesses a deep understanding of user-industry processes. An extensive manufacturing and quality assurance infrastructure ensures that world-class designs are transformed into high performance products.

For example:  ASME Class 300 Full Bore
Locking Device Trunnion Mounted Ball Valve Low Torque Antistatic Spring Loaded Seat 0
Overal Feature
Application
Isolation
Features / Benefit
Full Bore, Reduce Bore
Blow Out Proof Stem
Low Torque, Antistatic Device
Spring Loaded Seat, Stem Extension
Locking Device, Double Block & Bleed, Drain & Vent,
Self Relieving Seat / Double Piston Seat,
Corrosion Resistant Low Friction Bearing,
Emergency Sealant Injection
Trunnion Mounted Design Stem
Fire Safe Test Requirement as per API 607 & API 6FA
Ansi Class / Rating
150#, 300#, 600#, 900#
Design Standard
API 6D, BS EN ISO 17292 , ASME B16.34,
Testing Standard
API 6D, API 607, API 6FA,
F to F Standard
API6D, ASME B16.10
End Connection Standard
ASME B16.5, ASME B16.47
Size
50 mm to 1200 mm
Materials
Body : A105, LF2, LF6, F304, F316 etc
Seat : RPTFE, GFT, CFT, Viton, Peek, Devlon etc
Ends
Flanged End, Butt Weld End, Ring Type Joint
Operation
Mannual with Gear, Pneumatic, Electric, Gas Over Oil, Gas Powered, Hydraulically Operated etc

2 Piece Trunnion Mounted Ball Valve
Product Type of Seat  Series Range  Material of Construction
  Soft Seated

#150

#300

#600

#900

2''- 24''

2''- 24''

2''- 12''

2''- 12''

Body : WCB, CF8, CF8M, CF3, CF3M
Ball : WCB, CF8, CF8M, CF3, CF3M
Seat: DEVLON, PTFE, RPTFE



3 Piece Trunnion Mounted Ball Valve

Product Type of Seat Series Range Material of Construction
  Soft Seated

#150

#300

#600

#900

#1500

2''- 56''

2''- 56''

2''- 56''

2''- 36''

2''- 24''

Body : A105, F304, F316, F304L, F316L
Ball :A105, F304, F316, F304L, F316L
Seat: DEVLON, PTFE, RPTFE



Fully Welded Trunnion Mounted Ball Valve

Product Type of Seat Series Range Material of Construction
  Soft Seated

#150

#300

#600

#900

#1500

2''- 40''

2''- 40''

2''- 24''

2''- 16''

2''- 16''

Body : A105, F304, F316, F304L, F316L
Ball :A105, F304, F316, F304L, F316L
Seat: DEVLON, PTFE, RPTFE



Top Entry Trunnion Mounted Ball Valve

Product Type of Seat Series Range Material of Construction
  Soft Seated

#150

#300

#600

#900

#1500

2''- 40''

2''- 40''

2''- 24''

2''- 16''

2''- 16''

Body : WCB, CF8, CF8M, CF3, CF3M
Ball : WCB, CF8, CF8M, CF3, CF3M
Seat: DEVLON, PTFE, RPTFE
