Gold top valve located in Oubei Town, Wenzhou, China,where can make all kinds of precision balls,including top entry,metal seat and V type balls.On this base,our products range of floating,trunnion,Gate globe check valve ,butterfly valve ,etc.Surely we can design them by customer's special requirements.
 |
| Place of Origin: | 中国 |
| Brand Name: | GOLD TOP |
| Certification: | API 6D |
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Price to be negotiated in person. |
| Packaging Details: | Plywood Case |
| Delivery Time: | 30 days |
| Supply Ability: | 100+pcs+30 days |
| Size: | 2''-60'' | Design: | API 6D API 6A |
|---|---|---|---|
| Temperature Range: | -50° To 200°C (-58° To 392°F) | End Connections: | RF RTJ SW |
| Construction: | Three Piece | Port: | Reduce Or Full |
| High Light: | electrically actuated ball valve,floating type ball valve |
||
Design Features
The ball valve is designed in accordance with ISO17292,API 608,BS 5351,GB/T 12237;
Basic design with good tightness and small torque;
Reduced bore type and full bore type with a minimum flow resistance (zero actually);
Low emission packing;
Fire safe, anti-static and anti-blowout stem design;
Optional locking device
Optional ISO 5211 top flange
Product Range
Body material: carbon steel, stainless steel, alloy steel, exotics.
Nominal diameter:1/2"～6"(DN15~DN150)
End Connection: RF, RTJ, BW, THR, SW
Pressure range: Class150 – 2500(PN16~PN420)
Working temperature: -46℃- +200℃
Operation: wrench, worm gear, electric, etc
| SIZE | 1/2"-10" |
| RATING | ANSI 150LB-600LB |
| BODY MATERIALS | Carbon Steel, Stainless Steel,Alloy Steel |
| TRIM | PER ORDER REQUEST |
| SPECIFICATION | API 6D;ANSI B16.34;DIN;BS;JIS |
